Disposable Cup Electrodes

EEG Disposable Cup Electrodes

These disposable cup electrodes are ideally suited for use with the BraiNet electrode template in the neuro ICU, emergency department or other critical care environment.  Single patient use only.

Cadwell Disposable EEG Cup Electrode Pack

Cadwell's disposable EEG 10mm deep cup electrodes are single use, silver / silver chloride EEG electrodes designed to provide low impedance in routine and long term EEG studies, reduce patient infection, and are conveniently packaged with 25 multi-colored leads per pack.


The following Cadwell disposable EEG Cups are in convenient 25 packs:

12" (0.3m) Cadwell part # 302642-000-012
48" (1.2m) Cadwell part # 302642-000-048
60" (1.5m) Cadwell part # 302642-000-060

The following Cadwell disposable EEG cups are in a 15 pack typically used for PSG studies.
 98" (2.5m)  Cadwell part # 302642-000-098

User Benefits
• No cleaning and preparation of EEG electrodes needed
• Clear and reliable signal due to optimized layer of frequency stable Ag/AgCl
• Optimized signal quality due to larger electrode surface
• Short cup-to-cable connection to reduce lift risk
• Optimized connector for easy headbox insertion and extraction
• Optimal patient comfort with low profile disk, soft and flexible anti-tangle lead wires
• Reduced risk of cross-contamination

Colors included in each 25 pack are:

2 Blue, 2 Yellow, 2 Purple, 2 Orange, 2 Green, 2 Brown, 2 Grey, 3 Red, 3 Black, 5 White
